Bucket Elevator
Vertical transfer for bulk material where floor space will not allow an inclined run.
- Lift height
- 3 – 12 m
- Bucket volume
- 5 – 40 L
- Throughput
- 5 – 60 m³/h
- Motor power
- 2.2 – 11 kW
Overview
A bucket elevator raises bulk material vertically using buckets fixed to a chain or belt. It is used where material has to gain height in a short horizontal distance — feeding a silo, a screen or a press hopper in a plant where an inclined conveyor would not fit.
Bucket size, spacing and travel speed are selected according to the density and flow characteristics of the material being handled.
Key points
- Gains height in a short horizontal distance
- Bucket size and spacing selected per material
- Feeds silos, screens and press hoppers
